≥15-inch external color LCD touchscreen with a detachable display. The screen angle can be freely adjusted for comfortable viewing and reduced operator fatigue.
Magnetic stirring system inside the retort enhances reagent circulation, improving reagent penetration and tissue processing efficiency.
Reagent management system monitors reagent capacity and usage cycles, with automatic alerts when preset limits are reached.
Three-section photoelectric liquid level sensors continuously monitor reagent levels with built-in redundancy, ensuring uninterrupted operation even if one sensor fails. (No ultrasonic sensors.)
Stores ≥20 processing programs to meet a wide range of tissue processing requirements.
Specifications
Retort
5 L capacity, processing ≥380 tissue cassettes per cycle.
Paraffin Wax Chambers
≥3 wax chambers, each with a capacity of ≥5 L.
Individually adjustable temperature: Ambient to 65°C.
Reagent Bottles
≥14 built-in reagent containers, including 1 condensate container.
Liquid Control System
Multi-port rotary valve made of special ceramic material, resistant to paraffin buildup and designed to prevent pipeline blockage.
Functional Features
Dual-redundancy design for critical systems, including the gas circuit, heating, and temperature measurement systems. If any component fails, the system automatically switches to the backup component to ensure the tissue processing cycle is completed.
The tissue processor chamber lid features an independent computer-controlled temperature system, effectively reducing reagent condensation and preventing condensate from entering the gas circuit. The lid heating temperature range is room temperature to 70°C.
The bottom of the tissue processing chamber features a 5° inclined design to ensure smooth liquid drainage and reduce reagent residue. The liquid outlet adopts a raised hemispherical grid design for effective filtration, preventing residue from flowing back and clogging the pipeline.
The processing chamber lid and paraffin wax chamber lid are made of anodized aluminum alloy rather than marble, offering excellent antibacterial, wear-resistant, and corrosion-resistant properties. They are also less prone to reagent adhesion, making them easy to clean.
The chamber lid lock adopts a mechanical buckle design with fewer motorized components, resulting in a lower failure rate and reduced maintenance costs. Combined with a high-temperature- and corrosion-resistant sealing ring, it ensures stable airtightness inside the chamber.
The reagent storage area features a semi-transparent design and magnetic doors, ensuring convenient opening and closing as well as secure closure.
Reagent compartment background lighting allows users to clearly observe reagent filling and usage status. A red indicator light alerts users when a reagent container connection is abnormal.
Built-in backup UPS power supply automatically switches on in the event of a power outage.
Remote alarm and fault notifications can be sent via SMS, telephone, or email, allowing users to receive alerts and fault information remotely.
