1. Streamlined housing design with a clean and modern appearance. The top of the instrument can be used to store commonly used tools such as blades, paraffin blocks, and slides.

2. Equipped with a new cross-roller guide rail and micron-level specimen feed system, providing long-lasting lubrication without the need for oiling.

3. The handwheel can be locked at any position to ensure operator safety.

4. Newly designed high-performance disposable blade holder delivers optimal sectioning results.

5. Lateral blade holder movement allows full utilization of the entire blade edge.

6. Ergonomic design for more comfortable operation.

Vertical Stroke	60 mm +1 mm	Section Thickness Setting	Capacity:700ml
Horizontal Stroke	Approx. 24 mm ±1 mm	Specimen Orientation	Horizontal: ±8°/Vertical: ±8°
Blade Holder	Lateral adjustment function,3-point positioning	Specimen Holder Drive Mode	Standard specimen holder max. sample size:30* 40 *7mm; mechanical advance
Section Thickness Range Trimming Thickness Range	0-60μm	Rapid Trimming Mode	Two fixed settings:10μm and 30μm
Handwheel Rotation Direction	Clockwise for specimen advance, counterclockwise for specimen retraction	Large Handwheel Lock	2 locks (360° arbitrary locking+ top dead center lock)
Specimen Retraction	In manual slicing mode: 30μm (can be disabled)
Section Thickness Setting	Range:0 -60μm Settings: 0.5-2μm (0.5μm increments) 2-10μm (1μm increments) 10-20μm (2μm increments) 20-60μm (5μm increments)
